Gartec Aritco 9000 Cabin Platform Lift Commercial Access Lift

Previous Product | Next Product

Product Description

The Aritco 9000 Cabin Platform Lift is a functional, low cost and reliable enclosed cabin platform lift which is a great alternative to a conventional lift for almost any project. Fully compliant with Part M and the Equality Act and ideal as a wheelchair lift or access lift, the Aritco 9000 cabin lift offers a familiar surrounding with quick installation.

The Aritco 9000 enclosed cabin lift is a simple, cost effective and efficient direct replacement for a conventional lift, combining the best of both worlds and making it ideal for the accessibility and disability markets. The Aritco 9000 uses a modular structure to reduce delivery and installation time, needing only a load bearing footprint and no major building works on site.

The Aritco 9000 cabin platform lift is completely contained within the supplied lift shaft, and operated using Gartecs/Aritco's patented nut & screw technology, with a mast running behind the platform. The lift doesn’t require a machine room or pump box housing, meaning a one off installation will solve access needs immediately. Operation of the lift is through a single touch button on the platform, and for calling the lift to the floor.

FEATURES

- Up to 13m (6 stops) with up to 2 doors per floor

- Enclosed cabin lift (for open lift please see our other Gartec Products)

- 2 platform lift sizes

- 75mm pit or ramp

- No head room, machine room or pump box

- Quiet and energy efficient lift

- Internal wall designs and shaft RAL colours

- 8 flooring options

Contact ‘Aline Mobility’ the approved supplier and Installer of the full Gartec/Aritco Range within the UK, for a free site survey visit and no obligation, free estimate.

We can also provide approximate prices over the phone for the full installation of equipment, you can request a full colour brochure, or if you just need some advice on the various platform lifts available and where to start then we are here to help! For a definitive quote we would need to carry out a Free Full Site Survey for our engineers to assess layout, dimensions etc, and then we can provide a full quotation. Please contact us to arrange a mutually convenient appointment for our engineer to visit.

Specification

Drive System	Self-sustaining patented screw/nut system
Rated speed	0.15m/s
Landing control	One touch call
Platform control	One touch run
Technical Compliance	European machine directive 2006/42/EC
Rated load	400 kg/5 persons
Number of stops	Max. 6
Number of doors	Max. 2 doors per floor
Pit / Ramp	75 mm pit (or 75mm ramp)
Environment	Indoor only
Power	3-phase, 400V, 50Hz, 18A supply
Emergency lowering	Automatic lowering from car

Control supply	24 V
Motor	3.0 kW

Measurements

Cabin Sizes (WxDxH)	1000 x 1400 x 2100mm 1100 x 1400 x 2100mm
Structural Opening Width	Cabin width +465mm
Structural Opening Depth	Cabin Depth +230mm
Headroom Req.	2400mm
Travel height	2150-13000 mm
Doors B Side (opposite mast)	+25mm on all width dimensions
