Gartec Aritco Homelift Vertical Through Floor lift

Previous Product | Next Product

Product Description

The Aritco HomeLift (AHL) is a desirable home lift choice for homeowners, due to its aesthetics and design options. It offers a design statement to the home and lights up a hallway with the desired colour lighting. Many of our customers choose this lift to add an extra modern and luxurious touch to a project, whether they require a lift for a house with multiple floors, such as townhouses, for accessibility or to add ease and help with daily tasks.

Contact ‘Aline Mobility’ the approved supplier and Installer of the full Gartec and Aritco Range within the UK, for a free site survey visit and no obligation, free estimate.

We can also provide approximate prices over the phone for the full installation of equipment, you can request a full colour brochure, or if you just need some advice on the various platform lifts available and where to start then we are here to help! For a definitive quote we would need to carry out a Free Full Site Survey for our engineers to assess layout, dimensions etc, and then we can provide a full quotation. Please contact us to arrange a mutually convenient appointment for our engineer to visit.

Specifications

Type of Lift	Gartec HomeLift intended for installation in private homes
Technical Compliance	European Machine Directive 2006/42/EC, European Standard EN81-41
Drive System	Screw & Nut System
Installation Environment	Internal
Installation	Recess installation pit: 40mm below floor Install direct on floor: 40mm ramp
Rated Speed	Max 0.15m/s
Power Source	1ph 230V 20A

MEASUREMENTS

Travel Height	250 – 15,000mm
Top Height	Minimum 2225mm
No. of floors	2 to 6 floors
Call Button Controls	One touch operation
Carrier Control Panel	Hold to run (continuous pressure)
Carrier Sizes & Rated Load	S5 600 x 830mm 250kg / 2 person S8 1000 x 830mm 250kg / 3 person S9 1100 x 830mm 250kg / 3 person S12 1000 x 1200mm 300kg / 4 person S15 1100 x 1400mm 400kg / 5 person

Safety

Aritco has developed its SmartSafety system to make the whole family feel completely safe. This includes smart doors that know if something is in the way, and if so, automatically opens or closes again. It is also possible to lock the lift, preventing children or anyone else from using it.

Incase of a power failure the lift will run on batteries, so you are always able to lower the lift to the nearest floor and get out. There is also an alarm button that is connected to an autodialer, which can be used to make emergency calls to contact one of the pre-programmed numbers from the lift.

DESIGN YOUR LIFT

You can customize your Aritco HomeLift Access with a lot of options, such as colors, DesignWalls, floorings, etc. Below you can try design combinations of DesignWalls and colors to find a look that suits your preferences. If you want to try more combinations, visit our lift configurator LiftGuide.

Diagonal

Geometric Blue

Geometric Classic

Geometric Pink

Keywest

Orange

Orientalic

Pink

Sheets

Skyline

Structure
