VIMEC E10 Commercial Public Access Platform Lift

Previous Product | Next Product
Product Description

The Vimec E10 is our quiet, energy efficient MRL (Machine Room Less) enclosed passenger cabin lift. It has all the standard features you can expect from a traction lift such as automatic telescopic doors, but with extra options such as self-supporting glazed structure to give the look and feel of a conventional lift at a fraction of the price, with less building work in connection to installation.

Contact ‘Aline Mobility’ the approved supplier and Installer of the full Vimec Range within the UK, for a free site survey visit and no obligation, free estimate.

We can also provide approximate prices over the phone for the full installation of equipment, you can request a full colour brochure, or if you just need some advice on the various platform lifts available and where to start then we are here to help! For a definitive quote we would need to carry out a Free Full Site Survey for our engineers to assess layout, dimensions etc, and then we can provide a full quotation. Please contact us to arrange a mutually convenient appointment for our engineer to visit.

Specification



Type of Lift

Enclosed cabin lift intended for use in public & commercial environments

Drive System

Double belt traction drive system

Rated Speed

Max 0,15m/s

Travel Height

350mm – 14,600mm

Rated Load

400kg

No. Floors

2-5

No. Doors per floor

Max. 2 doors per floor

Pit

120mm or 140mm (with structure)

Entry

Single, through or adjacent entry (maximum 2 doors per floor)

Top Enclosure Height

Minimum 2600mm (based on 2000mm height cabin and doors)

Platform & Landing Controls

One touch control

Environment

Internal and external

Emergency Lowering

Battery operated emergency lowering / EMO (Emergency movement operation)

Control Voltage

24V

Motor

3kW

Power Supply

1-phase 230V 50 Hz/9 A/20 A slow

Communication

Arrival gongs, voice announcation, autodialler or autodialler with GSM unit

Enclosure

The VIMEC E10 can be installed into a existing shaft, alternatively the lift can be provided within it’s own self-supporting structure including glass or solid shaft panels

Shaft Lighting

Included as standard – Directive 2006/42/EC

Doors

2, 3, 4 stage telescopic sliding doors, one or two hour fire doors rated available if required



The lift is designed with simplicity in mind, meeting all requirements for quality, and safety. It looks, feels, performs and operates like a conventional passenger lift, with no machine room or deep pit required, offering complete freedom in design and simple usability, providing total safety in use. The energy efficient traction drive and fully automatic telescopic doors make it a versatile, cost effective passenger lifting solution. It is a perfect fit for tough and demanding environments such as offices, care homes, schools and residential buildings.

Fitted into your existing shaft, or supported in it’s own structural frame, the Vimec E10 provides a familiar user experience and single touch controls, with fantastic sustainability and simple electrical operation.

Ideal as an office lift, it offers compliance with building regulations Part M and the Equality Act whilst making users comfortable with the surroundings. With no machine room required, the lift takes up minimal space. The Vimec E10 is an ideal meeting of simple, low cost traction lift technology, and all the features you expect from a conventional lift – with the option of a glass shaft as well, providing a stylish and familiar access choice for users.
